# Timeout configuration

You can configure your web SDK to time out after a specified time.

This is useful for scenarios where a user cannot complete a step for whatever reason: maybe the [Scan ID capability](/platform/capabilities/scan-id) cannot recognize a document, or a document's barcode cannot be scanned due to poor lighting conditions, or another reason entirely.

You can do this by using two props: `onError` and `scanTimeout`.

Depending on whether you're running in classic mode or [device-to-device](/platform/sdk/web/d2d) mode, you'll need to configure your SDK differently.

The timeout applies only to the interactive document scanning steps:

- [Scan ID](/platform/capabilities/scan-id)
- [Scan & Verify ID](/platform/capabilities/scan-verify-id)

## Scan timeout

The `scanTimeout` prop takes in a value in **milliseconds** and presents a **timeout screen** when the configured value is reached:

<div style={{textAlign: 'center'}}>
  <img src="/platform/img/timeout-screen.png"
   alt="Timeout screen"
   style={{
     width: '50%',
     filter: 'drop-shadow(0 10px 8px rgb(0 0 0 / 0.4))'
     }}
   />
</div>

:::note
The timeout counter starts as soon as the camera is activated (even before users press **Start** on the modal).

The timeout works **per-step**. So, starting from the camera mount during a Scan ID or Scan & Verify ID functionality.
This means that you won't hit a timeout if you never start any scan.
:::

## Error callback

When the user presses **Continue another way** (in classic mode), the `onError` callback is triggered and your logic for what should happen then—activates.

The callback returns an object which contains diagnostic information:

- which [capability](/platform/capabilities) was used
- what was the [transaction ID](/platform/api/transaction-api)
- what was the type of the error (currently only `ERROR_SCAN_TIMEOUT` is returned)

## Configuration for classic mode

When you use the SDK in classic mode, configure the timeout in the following way:

```js title="Classic mode configuration"
{
  mode: "classic",
  scanTimeout: "60000",
  onError: () => {
    window.location.assign('/');
  }
  // rest of configuration here
}
```

Or, if you want to be explicit that it should expect the `ERROR_SCAN_TIMEOUT` value:

```js title="Explicit expectation of the value returned in case of a timeout"
onError: (errorData) => {
  if (errorData?.errorType === 'ERROR_SCAN_TIMEOUT") {
    window.location.assign('/');
  }
}
```

When the `onError` callback is defined, in classic mode, it has to be accompanied with the `scanTimeout` configuration as well.

## Configuration for device-to-device mode

In device-to-device mode, you don't need to set the `onError` prop at all.

You can set the `scanTimeout` value, and in case that the value is reached, the user is redirected back to the primary app, where the `onError` callback is activated.

```js title="D2D mode configuration"
{
  mode: "d2d",
  scanTimeout: "60000",
  // rest of configuration here
}
```

## Possible scenarios

Here are some possible combinations between the primary and secondary (D2D) apps.
We describe the behavior of the system based on different configurations.

1. Neither `scanTimeout` nor `onError` are configured on any app:
   - Nothing happens on both apps.
2. Only `scanTimeout` is configured, and only on the primary app:
   - Nothing happens on both apps.
3. Both `scanTimeout` and `onError` are configured only on the primary app:
   - When the camera UI is shown, `scanTimeout` starts counting.
   - When it hits the limit, the timeout error UI is shown with options **Try Again** and **Try Another way**.
   - When **Try Another Way** is selected, it triggers the `onError` callback.
   - Nothing happens on the secondary app.
4. Only `onError` is configured on the primary app, only `scanTimeout` is configured on the secondary app:
   - When the user scans a document on the secondary app, a timer starts counting.
   - When the limit is reached, the user is presented with the timeout error screen on the secondary app with the options **Try Scanning Again** and **Switch to Desktop and continue**.
   - When user selects the "switch to desktop" option, the primary device receives this event, switches the user back to the primary app and executes the `onError` callback **on the primary device**.


Last updated on Apr 16, 2026
